NT90MT

Conference Systems · HD Video Conference System

The brand-new integrated HD video conference terminal integrates a 4K HD camera and a microphone, featuring exquisite appearance and excellent performance. It supports H.265 technology and achieves ultra HD effects with ultra-low bandwidth. The simple installation method of the terminal makes it suitable for various small and medium meeting venues.

Features

• Adopt an integrated structure, built-in hardware video processing unit and integrated 4K HD camera; embedded Linux operating system, non-Windows/Android operating system; built-in hardware video processing unit.
• Support ITU-T H.323, SIP standard protocol, with good compatibility; support H.239, BFCP dual-stream protocol; support mainstream up to 4K, and auxiliary stream 1080P.
• Support 64Kbps-8Mbps call bandwidth; support CIF, 4CIF, 720P, 1080P, 4K video resolution.
• Support 1280*720 60fps/50fps/30fps/25fps, 1920*1080 60fps/50fps/30fps/25fps HD video signal input.
• Support 1024*768 60fps, 1280*720 60fps, 1920*1080 60fps/30fps, 3840*2160 60fps/30fps HD video signal output.
• Support H.261, H.263, H.263+, H.264, H.264 HP, H.265 video codec protocol, support G.711, G.722, G.722.1, G.722.1C, OPUS and other audio codec protocols, the sound quality is up to 48KHz.
• Built-in MCU function module, support 4-party meeting, support smooth extension to 8-bit built-in MCU function; support built-in MCU holding main and auxiliary stream meetings; support PC client or mobile terminal joining the meeting.
• Support controlling the terminal through 2.4G remote control, web, touch, mouse and keyboard, etc.
• Support turning on and off the remote video flexibly; support dragging and dropping to change the window position of the video in the screen layout by flying mouse.
• Adopting B/S management structure, users can log in to WEB for remote management through a browser; support switching between Chinese and English.
• No need to register, just enter the meeting number to join the corresponding meeting, and you can choose to join the meeting in the interactive mode or live mode.
• Support the chairman control mode. After applying for the chairman authority, you can control the dual-stream encoding rate, resolution and other parameters of all remote venues; support moving up, down, left, and right, focusing, and zooming operations on the PTZ camera at the remote venue.
• The main screen supports the output of 4K signals; a single screen can actively open 25 channels of video screens at the same time, and can display the main and auxiliary stream screens of multiple venues at the same time.
• Support single-screen dual-display, dual-screen dual-display application functions, so as to realize multi-screen layout; support picture-in-picture and other common layouts.
• Support wireless streaming function; only need to install a software on the computer, connect to the terminal through the network to realize the wireless shared streaming function, no need for external hardware devices.
• Supports setting the full-screen display or composite display of the auxiliary stream in the meeting.
• Support the annotation function of the auxiliary stream; you can make real-time annotations on the auxiliary stream screen when sending or receiving the auxiliary stream; you can set three brush thicknesses, five brush colors, and annotate graphics such as circles, squares, arrows, and lines; when sending content, you can set whether to open the annotation permission to the participants for interactive annotation.
• Support dual-stream bandwidth control of all remote venues; support PTZ control of remote venues.
